Presonus CDL10P Line-Array Speaker

PRE-CDL10P - RRP $2,117.64
In store: None
Online: Yes
Online
$1,799.00
  • MasterCard
  • VISA
  • American Express
  • PayPal
  • Zip
  • Apple Pay

free

shipping!*
6

year warranty

Presonus CDL10P Line-Array Speaker
Presonus CDL10P Line-Array Speaker
Presonus CDL10P Line-Array Speaker
Presonus CDL10P Line-Array Speaker
Presonus CDL10P Line-Array Speaker
Presonus CDL10P Line-Array Speaker

Frequently Asked Questions

What are the shipping rates?

We offer free shipping on orders $100+ and under 32kg to metro areas in ACT, NSW, VIC, and QLD. If you are in a regional area we will subsidise your delivery rates. You can calculate shipping in the checkout and on product pages with your postcode.
All orders under $100 are charged at minimum $10 shipping.

Basic vs Standard vs Express Shipping

Express 1-5 days.
Standard 2-10 days.
Basic 4-10 days.
Our shipping platform will automatically determine and display the Express or Standard shipping options that are available to you.
Delivery times are determined by how far you are away from our store in Canberra.
If Express is not displaying, you're either located too far away from our store in Canberra, or the Standard shipping option will get it to you just as fast for the same price.

What payment methods do you offer?

We offer secure checkout options like Visa, Mastercard, PayPal, Zip Pay and Bank Deposit.
American Express payments are also accepted, although most AmEx transactions will require manual authorization after payment (Someone from the team will contact you to confirm the transaction after checkout)

Can I cancel my order?

If you need to cancel your order it is best to give our online team a call on (02) 6282 3199
On weekends our online team may not be operating. Either give us a call Monday morning or reply to your order email and we will get back to you asap.

Need Assistance?

Feel free to contact us by phone, email or chat

  • (02) 6282 3199
  • Talk to our experts on live chat
  • 18 Salamander Court, Phillip 2606, ACT
  • Map
Highlights
  • Unique patent-pending driver design for clear audio
  • Lightweight design ideal for touring bands and DJs
  • Hybrid point-source/line-array for focused sound
  • Integrated 500W x 500W Class D amplifier
  • Onboard DSP presets for simplified configurations
  • Rugged, lightweight enclosure for easy transport
  • Dual-angle pole mount supports multiple enclosures
Description

The CDL12 loudspeakers impressed ears around the world when we introduced them, thanks in no small part to their unique, patent-pending driver design that fills venues with consistent, articulate speech and music reproduction without sacrificing consistent SPL. Now that same constant-directivity performance is available in the new CDL10P, a lighter-weight design ideal for touring bands and mobile DJs who want the same scalability and sonic performance in portable design.

Like the CDL12P, CDL10P is the result of years of research and development, combining the best attributes of point source and line array technology into a unique patent-pending design. You get clear, articulate speech intelligibility and natural music reproduction thanks to its highly focused pattern with consistent SPL throughout the frequency response range, both on- and off-axis.

The CDL10P's hybrid point-source/line-array design delivers focused sound with consistent SPL coverage both on- and off-axis, making it an excellent choice for mobile and installed applications. Rigging CDL10P enclosures is made easier thanks to integrated pin-loaded rigging hardware. A dual-angle pole mount is provided, supporting the use of one or two enclosures when pole-mounted. The CDL10P's integrated 500W x 500W Class D power amplifier features onboard DSP presets to facilitate and simplify arrayed configurations.

FEATURES

  • Continuous-directivity constant curve array with six 2-inch cone drivers disperses sound 120° horizontally
  • 15˚ vertical directivity can be extended from 30˚ up to 90˚ with additional arrayable CDL10P's
  • 10-inch, long-throw LF transducer with 2.5-inch voice coil
  • Low 420 Hz crossover point minimizes comb filtering and enhances line array intelligibility
  • 500 x 500 watts Class D power for high SPLs and lightning-fast transient response
  • Onboard DSP: 90 High-pass filter, Array Mode (1-6 boxes), Sub Mode (Off, CDL18s, ULT18, or AIR18s)
  • 35 mm pole socket with 7.5˚ downward tilt for use with up to two CDL10P on a tripod or atop PreSonus® CDL Sub18, CDL18s or ULT18 subwoofer
  • Integrated flyware to create an array of up to six CDL10P's
  • Signal, -3 dB, Limiter Protection, and Clip Monitoring
  • Rugged, lightweight plastic enclosure and tour-grade, 1.2 mm steel grille - great for touring bands and mobile DJs

THE CDL10P’S CONSTANT DIRECTIVITY DESIGN
Each CDL10P consists of 6 2-inch drivers aligned in a segmented, circular-arc, HF array centered in front of a 10-inch woofer. The output of the LF driver travels from the same acoustic axis as the HF array so the pattern always radiates from the center. This avoids near-field anomalies and makes the CDL10P ideal for a broad range of venue sizes.

MORE ABOUT THE CDL10P’S HF DRIVER ARRAY
The 2-inch cones’ fast transient response is matched for high- and mid-range reproduction. This is enhanced by setting the internal crossover to 420 Hz, so the CDL10P reproduces audio seamlessly, with no gaps at the heart of the musical range. This also minimizes comb filtering between 10-inch bass drivers in an array for a smooth low-mid response.

CDL10P POWER AMPLIFICATION
Each 2-inch speaker in the high-frequency driver array has a 1-inch voice coil, and the entire array is driven by a 500W Class D amplifier. Because the power is shared across six voice coils, power compression is reduced, resulting in an efficient design and a flatter phase response for less fatiguing listening and a refined, balanced sound.

CDL-SERIES RIGGING ACCESSORIES
CDL loudspeakers and rigging hardware are rated for a 10:1 load. The CDL10P Rigging Grid is required for flown installations. The CDL Rigging Extension Bar provides tilt control. The CDL10P Rigging Sling is required with 4 or more CDL loudspeakers in a vertical array and when using the CDL Rigging Extension Bar with a tilt of 12˚ or greater.


More Information
More Information
Brand Presonus
Speaker type Line Array
Active or Passive? Active
Speaker size? 10"
# inputs? 1
Wattage 500 x 500w Class D
Got bluetooth? No
Power source Mains
Built in effects? No
